Spec Sheets, CAD & Warranty Docs for Architects & Specifiers
Texas Made Shade is a full-service fabrication shop in Seguin, TX — we design, fabricate and install welded aluminum awnings, tensioned sail-shade structures.
Need engineered, stamped plans for permitting or a commercial submittal? We can have those produced for you through the licensed Texas engineers we work with — just let us know with your spec request and we'll fold the engineering scope into your quote.
Documents We Can Provide for Your Commercial Project
Tell your reviewer or engineer what they need and we'll get it to you — spec sheets, sample drawings, mockups and warranty docs. These are available options, pulled together per project, so you're not chasing loose paperwork.
Fabric Spec Sheets
Manufacturer data sheets for every awning canvas and shade fabric we install. UV ratings, tensile strength, fire-rating and warranty terms.
- Sunbrella® Marine, Furniture & Awning grade
- Tempotest® Heritage and Star marine canvas
- Serge Ferrari® Soltis & precontraint shade fabric
- Phifertex® coated polyester mesh
CAD & DWG Samples
Representative DWG / PDF samples for welded aluminum awning frames, sail-shade post assemblies and pavilion enclosures.
- Storefront entry & dome awning frames
- Sail-shade post + tension hardware details
- Cantilever covered-parking post sections
- Pavilion drop-curtain enclosure layouts
Hardware Schedule
Standard hardware schedule used on Texas Made Shade commercial structures — stainless tension hardware, welded brackets, anchor specs.
- Stainless tension fittings & turnbuckles
- Welded steel posts — engineered to local wind load
- Engineered concrete footing details
- Powder-coated finish schedule (RAL match available)
Engineering Letters
Stamped engineering for permitted commercial sail-shade, awning and covered-parking work — coordinated with licensed Texas PEs.
- Site-specific wind / uplift calcs
- Stamped TX PE letters on request
- Coordination with GC and AHJ
- Engineered footings and post sections
Warranty Documentation
Frame, fabric and hardware warranty docs provided with your project documentation on request.
- 10-year structural frame warranty
- 10-year Sunbrella® / Tempotest® canvas
- 10-year Serge Ferrari® / Phifertex® UV
- Workmanship warranty on installation
Full Submittal Packages
AIA-style submittal packages assembled per project — formatted for the architect or general contractor's submittal process.
- Fabric & hardware data sheets
- Frame & finish schedule
- Stamped engineering letter
- Warranty + maintenance documentation
Specify Texas Made Shade by Application
Each pillar service page below includes representative photos, fabric and frame specs, FAQs and our standard warranty terms for that application.
- Commercial AwningsStorefront, restaurant, hotel & office entry awnings.View spec page
- Restaurant AwningsBranded patio canopies & walk-up window awnings.View spec page
- School Shade StructuresPlayground, cafeteria & athletic shade for ISDs.View spec page
- Church Shade StructuresCourtyard, entry & pavilion shade for churches.View spec page
- Car Wash Shade SailsVacuum bay & detail bay engineered shade sails.View spec page
- Covered Parking StructuresCantilever & sail covered-parking shade.View spec page
- Playground Shade SailsEngineered playground sails for schools & parks.View spec page
- Sail ShadesEngineered tensioned sail-shade structures.View spec page
- Patio CoversWelded aluminum residential & commercial patio covers.View spec page
- Custom FabricationWelded steel & aluminum structural fabrication.View spec page
Send Us Your Project — We'll Send a Full Spec Package
Email specs@texasmadeshade.com with project type, location, AHJ and what your reviewer needs. We'll pull together the documentation for your project — fabric data sheets, sample or mockup drawings, hardware specs and warranty docs — and coordinate stamped engineering letters with the licensed Texas PE on the job.
Ready to Spec Texas Made Shade?
Send the project type, location, AHJ and any wind/uplift requirements — we'll respond same business day with a written submittal.
